Securing Kubernetes
Hi, Y’all! It’s been way too long since I last wrote anything. I might list a bunch reasons for the long silence (among other things, I’ve found myself painting miniatures again — awesome!), but that’s probably not interesting to anybody so let’s get down to business shall we?
On this occasion, we’ll be looking into a pretty juicy topic. We’re going to marry HashiCorp’s Vault With a Kubernetes cluster for the purpose of serving (dynamic) secrets from Vault. You can follow along with my templates if you wish. Source code here.
Disclaimer
I’m not going to teach how to use the different tools that I’ve used setting up the experiment below. That would be tedious to read and to write.
So what is Vault?
“HashiCorp Vault is a tool for securely accessing secrets. A secret is anything that you want to tightly control access to, such as API keys, passwords, or certificates. Vault provides a unified interface to any secret while providing tight access control and recording a detailed audit log.”
So in short, it’s a one-stop-shop for all your secrets handling needs. For example, just imagine the hassle of renewing SSL certificates for an internal load balancer in AWS. The internal CA service that ACM offers is great, but it does come with a cost of 400$ (last I checked) a month which is quite expensive.
With Vault, you get a single API to renew, fetch and revoke your certificates — so no more openssl <try to remember the commands you use once a year>. Now you can easily write a small program (read: lambda handler) to renew your certificates for a fraction of the cost of an ACM provisioned internal CA.
Today though, we’re interested in injecting key-value pairs to containers being spun on a Kubernetes cluster. Normally people use the secrets API of Kubernetes to store and serve secrets as environment variables. Now, this approach is completely fine, but you really should take care of encrypting ETCDs disks and limit access to the secrets API if you take this route, and most people do.
Using Vault, however, to provision and store your secrets, is more operator and especially developer friendly IMO. “Why?” You might ask. Well firstly, secrets are only ever stored encrypted, even if the storage being used is not. Vault takes care, that nothing leaves its security boundary decrypted. It also takes care of decrypting when secrets are read from Vault. Another thing is easy IAM. Setting up fine-grained access policies is really simple. For example, here’s the Kubernetes service account policy I made for this exercise:
path "secret/*" {
capabilities = [ "read", "list" ]
}
path "sys/leases/renew" {
capabilities = ["create"]
}
path "sys/leases/revoke" {
capabilities = ["update"]
}
Easy!
For developers, Vault offers a single API endpoint for all of their secrets needs, including PKI certificates, cloud accounts etc. And the best part? Everything is auditable, TTL stamped, and operator controlled.
So let’s get cracking to see Vault in action.
Setting the environment
Now we set up a highly available Kubernetes and Vault clusters in AWS. You can follow along, but take note that I’m using a registered public domain for ease of use. You’ll need to either fork and adjust some parameters in the repo or get yourself a public domain to follow along.
Prerequisites
Kubectl.
Helm.
Ansible.
Terraform.
Packer.
Kops.
Vault CLI (optional).
AWS CLI (optional).
Pre-create SSH keys and output them to the appropriate directories, for example
ssh-keygen -t rsa -b 4096 -C "key@vault" -f keys/vault/vault_rsa.
Do the same for
kubernetes_rsa.
Topology
Typology
Step-by-step
1. Bootstrap the Terraform state
This will provide an S3 bucket and a DynamoDB table for Terraform remote state handling
./bootstrap.sh default eu-west-1
2. Setup basic networking
For this step, you’d be best to comment out vault.tf and kubernetes.tf. The latter will be rewritten soon.
terraform init # If this doesn’t work, check backend in main.tf
terraform plan # Check that output looks good
terraform apply -auto-approve
If everything went okay, you should see subnet IDs and a VPC ID in the output something like:
all_subnet_ids = [
subnet-093e9b3ab369ce081,
subnet-0543b5d10bd887a5b,
subnet-0a2497254954840d4,
subnet-06b1d6094b71fed3d,
subnet-01f0757b77ef3d4e1,
subnet-0f34944d2f036c22b
]
hyperspace_rep_arn = arn:aws:ecr:eu-west-
1:772545774134:repository/hyperspace
private_subnet_ids = [
subnet-0a2497254954840d4,
subnet-06b1d6094b71fed3d,
subnet-0f34944d2f036c22b
]
utility_subnet_ids = [
subnet-093e9b3ab369ce081,
subnet-0543b5d10bd887a5b,
subnet-01f0757b77ef3d4e1
]
vpc_id = vpc-07c93b78357bb8450
3. Packer build the Vault AMI
Next, let’s create the AMI that will be used for Vault instances. Copy-paste one of the utility subnet IDs to the Packer template:
“aws_region”: “eu-west-1”,
“subnet_id”: “subnet-093e9b3ab369ce081”, <=======HERE
“consul_download_url”: “{{env `CONSUL_DOWNLOAD_URL`}}”,
And then, run:
packer build -only=amazon-linux-ami vault-consul-ami/vault-consul.json
Take note of the build AMI ID, as we will need it soon. Now, let’s provision the Kubernetes cluster. I’ll be using KOPS and a ready-made bash script I wrote that incorporates output variables from Terraform.
4. Provision stuff
./create-k8s.sh
The script automatically exports a kubernetes.tf template and data directory with ASG launch configurations and AWS roles and policies. You’ll want to comment out at least the provider block and the vpc_id output block as they overlap with, but personally, I also commented out all the network-related outputs because of redundancy. They’re already being output elsewhere.
Now, if you run:
terraform planterraform apply -auto-approve
You should have a functional Kubernetes cluster with three masters and three minions divided into three AZs.
$ kubectl cluster-info
Kubernetes master is running at https://api.vault-demo.useless.mobi
KubeDNS is running at https://api.vault-
demo.useless.mobi/api/v1/namespaces/kube-system/services/kube-
dns:dns/proxy
To further debug and diagnose cluster problems, use ‘kubectl cluster-
info dump’.
$ kubectl get nodes -o wide
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-
VERSION CONTAINER-RUNTIME
ip-90–80–1–194.eu-west-1.compute.internal Ready node 12m v1.11.6
90.80.1.194
docker://17.3.2
ip-90–80–1–37.eu-west-1.compute.internal Ready master 14m v1.11.6
90.80.1.37
docker://17.3.2
ip-90–80–2–121.eu-west-1.compute.internal Ready node 13m v1.11.6
90.80.2.121
docker://17.3.2
ip-90–80–2–230.eu-west-1.compute.internal Ready master 14m v1.11.6
90.80.2.230
docker://17.3.2
ip-90–80–3–186.eu-west-1.compute.internal Ready node 12m v1.11.6
90.80.3.186
docker://17.3.2
ip-90–80–3–204.eu-west-1.compute.internal Ready master 14m v1.11.6
90.80.3.204
docker://17.3.2
Just as a side note: you don’t need to provision your environment as I have. Using a managed service like EKS is probably best for practice's sake. We’re not really interested in setting up the environment, only about using Vault with Kubernetes.
That said, I do personally like emulate stuff as much production-ready as I can. You don’t step into (all) the pitfalls if you play it safe. “Sweeping the minefield” at this point saves a lot down the road for sure.
Just a couple of steps more to get everything up and running. Next, we provision Vault. Uncomment the template if you haven’t already, input the AMI ID from the previous step and modify the allowed SSH CIDR for the correct address of the bastion node. Then run:
terraform init
terraform plan
terraform apply -auto-approve
5. Configure Vault and Kubernetes
First, provision a couple of “helper” stuff to Kubernetes:
$ kubectl apply -f kubernetes/
configmap/kube-dns created
serviceaccount/tiller created
clusterrolebinding.rbac.authorization.k8s.io/tiller created
clusterrolebinding.rbac.authorization.k8s.io/role-tokenreview-binding created
serviceaccount/vault-handler created
Especially the vault-handler service account is of interest here. We need it to authenticate with Vault. Now, to actually connect to Vault UI, which is accessible (only) internally inside our VPC, we will install an OpenVPN server to our cluster. For this, you’ll need to use Helm and the OpenVPN chart. Remember to go through the default settings. I personally used the custom-value.yaml.
Then fetch the SA token and cert like this:
VAULT_SA_NAME=$(kubectl get sa vault-handler -o jsonpath=”{.secrets[*][‘name’]}”)
kubectl get secret $VAULT_SA_NAME -o jsonpath=”{.data.token}” | base64 — decode; echo
kubectl get secret $VAULT_SA_NAME -o jsonpath=”{.data[‘ca\.crt’]}” | base64 — decode; echo
Modify correct IPs for the vault-nodes in ssh.config and Ansible’s inventory file. SSH yourself into a Vault node and initialize your Vault cluster: vault operator init. This will be the only time that Vault outputs the unseal keys, so take care of them!!! Ideally, you should distribute the keys among five different people, but for the purpose of this exercise, I’ll copy-paste the output to Ansible Vault. As you probably figured out already, we will be using Ansible to do SSH stuff (this is what I generally like to do), because all manual labor is evil.
Add the unseal keys, service account token and root CA certificate to vault-nodes.yml as follows:
unseal_key_1: ***
unseal_key_2: ***
unseal_key_3: ***
unseal_key_4: ***
unseal_key_5: ***
initial_root_token: ******
k8s:- k8s_sa_user_token: **********
k8s_ca_cert: |
— — -BEGIN CERTIFICATE — — -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—
— -END CERTIFICATE — —k8s_host: https://api.internal.vault-demo.useless.mobi:443
And then run the playbook:ansible-playbook -i inventory -l vault-nodes -t vault vault.yml — vault-password-file vault_pass
The final step is to add a DNS record to Route53 for Vault and volá, we’ve got a live (production-ready) Vault up and running.
The absolute last thing to do is to open access for Vault to talk with Kubernetes. For that, I’m adding the below AWS Security Group Rule configuration block to the kubernetes.tf template (anywhere in the template is fine).
resource “aws_security_group_rule” “https-vault-to-master” {
type = “ingress”
security_group_id = “${aws_security_group.masters-vault-demo-
useless-mobi.id}”
source_security_group_id = “${module.vault_cluster.security_group_id}”
from_port = 443
to_port = 443
protocol = “tcp”
}
To use secrets from Vault
So now, we’ve finally at a point where we can see some Vault magic. I’ve got a demo application ready-made if you don’t feel like using your own. There are a couple of points to note. Firstly, I’m adding an init container to the Kubernetes deployment manifest that fetches application secrets from Vault and writes them to disk that the parent container also maps.
spec:
serviceAccountName: vault-handler
initContainers:
- name: vault-init
image: everpeace/curl-jq
command:
- "sh"
- "-c"
- >
KUBE_TOKEN=$(cat /var/run/secrets/kubernetes.io/serviceaccount/token);
curl -k --request POST --data '{"jwt": "'"$KUBE_TOKEN"'", "role": "k8s-
admin"}' https://vault.useless.mobi:8200/v1/auth/kubernetes/login | jq
-j '.auth.client_token' > /etc/vault/token;
X_VAULT_TOKEN=$(cat /etc/vault/token);
curl -k --header "X-Vault-Token: $X_VAULT_TOKEN"
https://vault.useless.mobi:8200/v1/secret/dev/hyperspace >
/opt/secrets/secrets.json;
for i in $(cat /opt/secrets/secrets.json | jq -r '.data | keys[]'); do
echo "Export env: $i"
echo "export $(echo $i | awk '{print toupper($0)}')=$(cat
/opt/secrets/secrets.json | jq -r .data.$i)" >> /opt/secrets/.env
done
volumeMounts:
- name: app-creds
mountPath: /opt/secrets
- name: vault-token
mountPath: /etc/vault
So I fetch the secrets to a JSON dump, parse it to an environment variable file that I then source in the Dockerfile:
FROM golang:1.11.5-alpine
RUN apk update && apk add git
WORKDIR /opt/app
ADD . .
RUN touch /tmp/server.pid && \
ggo get github.com/lucasb-eyer/go-colorful && \
cd server && \
go build
ENTRYPOINT [ “sh”, “-c”, “. /opt/secrets/.env && env | grep SECRET && ./server/server -port 9393 echo $$! > /tmp/server.pid” ]
Logs should show the current values:
$ kubectl logs hyperspace-56fd89dbbd-w2j76SECRET_KEY=aoTieyaezoh8SUPER_SECRET_KEY=chu5iePak2Em
Hello, World!
Now go and change the secret values of said environment variables in Vault.
And kick the pod kubectl delete pods hyperspace-56fd89dbbd. Wait for the new pod come to life and check the logs.
k logs hyperspace-56fd89dbbd-gdtwr
SECRET_KEY=asdasdasd
SUPER_SECRET_KEY=rtyrtyrtyrty
Yey! It worked!
Before you go, please remember to delete everything terraform destroy -auto-approve :)
TL;DR
Kubernetes secrets is a mediocre solution at best, Vault is better but way more complex to set up. Choosing the best option is always a case-by-case call.
